System |
Operating system |
Android 11 |
Display |
Screen size |
8-inch |
Operation method |
Touch screen |
Type |
IPS |
Resolution |
800 × 1280 |
Video |
Lens |
2 |
Resolution |
2 MP |
Video standard |
PAL (Default) and NTSC |
Audio |
Audio input |
Not support |
Audio output |
Built-in loudspeaker |
Network |
Wired network |
1, RJ-45 |
Wi-Fi |
Support, 2.4 G, 802.11b/g/n |
Interface |
Network interface |
1 |
Lock control |
Support |
Exit button |
Not support |
Alarm input |
2 |
Alarm output |
1 |
USB |
1 type-C interface |
Capacity |
Face capacity |
100,000 |
Card capacity |
500,000 |
Event capacity |
500,000 |
Authentication |
Face recognition distance |
0.3 m to 1.2 m |
Face recognition accuracy rate |
≤ 99% |
Face recognition duration |
< 0.2 s |
Card type |
M1 card;DESfire card;Felica card |
Card reading distance |
0 cm to 5 cm |
General |
Supplement light |
IR supplement light |
Power supply |
12 VDC to 16 VDC |
Working temperature |
-10 °C to 50 °C (14 °F to 122 °F) |
Working humidity |
0 to 90% (no condensing) |
Dimensions |
129.1 mm × 309.5 mm × 137.1 mm (5.1″ × 12.2″ × 5.4″) |
Weight |
1.36 kg (3.0 lb) |
Application environment |
Indoor |
Language |
English, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Chinese Traditional |
Function |
Video intercom |
Not support |
QR code recognition |
Reserved |
Face anti-spoofing |
Support |
Time synchronization |
Support |
