| Network |
| Wired network |
10/100 Mbps self adaptive |
| Interface |
| Network interface |
1 |
| Lock control |
2 |
| Exit button |
2 |
| Door contact input |
2 |
| Alarm input |
4 |
| Alarm output |
4 |
| TAMPER |
1 |
| RS-485 |
2 for card reader (1 for communication, 1 for redundancy; each interface can connect up to 4 readers) |
| Wiegand |
4, standard 26/34 input, supports custom Wiegand settings |
| Fire interface |
Support |
| Capacity |
| Linked door capacity |
2 |
| Linked card reader capaciry |
4 RS-485 card readers (OSDP protocol) and 4 Wiegand card readers |
| General |
| Battery |
Charge and discharge |
| Power supply |
12 ± 15% VDC |
| Power consumption |
≤ 72 W |
| Working temperature |
-10 °C to 55 °C (14 °F to 131 ° F) |
| Working humidity |
0% to 90% (No condensing) |
| Installation |
Wall mounting |
| Language |
English, Thai, Traditional Chinese, Indonesian, Vietnamese, Arabic, Spanish (Europe), Spanish (South America), Italian, French, Dutch, Russian, Ukrainian, Portuguese (Europe), Portuguese (Brazil), Serbian, Croatian, Bulgarian, German, Greek, Romanian and Turkish |
| Function |
| Configuration via Web browser |
Support |
| Multi-factor authentication |
Support |
| Anti-passback |
Support |
| Multi-door interlocking |
Support |
