| Display |
| Screen size |
4.3 inch |
| Operation method |
Capacitive touch screen |
| Type |
LCD |
| Video |
| Lens |
2 |
| Resolution |
2 MP |
| Audio |
| Audio quality |
Noise suppression and echo cancellation |
| Network |
| Wired network |
Support |
| Interface |
| Network interface |
1 RJ-45, 10/100 M self-adaptive |
| Lock control |
1 |
| Exit button |
1 |
| Door contact input |
1 |
| TAMPER |
1 |
| RS-485 |
1 RS-485 (Half duplex, HIKVISION) |
| Wiegand |
1 Wiegand(Hik 26bit,Hik 34bit) |
| USB |
1 |
| Authentication |
| Card type |
M1 card |
| Card reading frequency |
13.56 MHz |
| General |
| Power supply |
12 VDC, 1 A (power adapter included) |
| Working temperature |
-10 °C to 40 °C (14 °F to 104 °F) |
| Working humidity |
0 to 90% (No condensing) |
| Dimensions |
118.4 mm × 118.4 mm × 21.8 mm (4.66″ × 4.66″ × 0.86″) |
| Installation |
Wall mounting, base mounting |
| Language |
English, Spanish (South America), Arabic, Thai, Indonesian, Russian, Vietnamese, Portuguese (Brazil), Korean; Japanese |
| Platform |
Hik-ProConnect and HikCentral Professional |
| Function |
| Face anti-spoofing |
Support |
