| Video and Audio |
| IP Video Input |
8-ch |
| Incoming Bandwidth |
60 Mbps |
| Outgoing Bandwidth |
60 Mbps |
| HDMI Output |
1920×1080/60Hz，1600×1200/60Hz，1280×1024/60Hz，1280×720/60Hz |
| Decoding |
| Decoding Format |
H.265,Smart265,H.264,Smart264 |
| Recording Resolution |
4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback |
4-ch |
| Decoding Capability |
4-ch@1080p (25 fps) |
| Stream Type |
Video, Video & Audio |
| Audio Compression |
G.711ulaw/G.711alaw/G.722/G.726 |
| Network |
| Remote Connection |
128-ch |
| Network Protocol |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, NFS, iSCSI, ISUP, UPnPâ„¢, HTTP, HTTPS |
| Network Interface |
1, RJ-45 10/100 Mbps self-adaptive Ethernet interface |
| Auxiliary Interface |
| Capacity |
1TB SSD (pre-installed) |
| USB Interface |
Rear panel: 2 × USB 2.0 |
| General |
| Power Supply |
12 VDC, 1A |
| Consumption |
≤ 10 W (with SSD) |
| Working Temperature |
-10 °C to 50 °C (14 °F to 122 °F) |
| Working Humidity |
10 to 90 % |
| Dimension (W × D × H) |
95 × 97 × 27 mm (3.7″ × 3.8″ × 1.1″) |
| Weight |
≤ 0.24 kg |
| Certification |
| CE |
EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017 |
