DS-D42B01-N

LED controller

  • Loading capacity up to 650,000 pixels, maximum width: 4096 pixels, maximum height: 4096 pixels
  • 2x Gigabit Ethernet ports
  • Allows for play content imported from a USB drive and firmware upgrade over USB
  • Processing Performance
    Brightness Control 1-100 Levels
    Frame Frequency 30HZ-60HZ
    Grey Level 256
    Display Color 1 Billion
    Processing Depth 8bit
    Image Scaling Support
    Product Model
    Product Model DS-D42B01-N
    Chassis
    Chassis Height 0.9U
    Chassis Width 3.12U
    Product Type
    Product Type LED Controller
    LED Controller Power
    Average Consumption ≤18W
    Number of power interfaces 1
    Power interface specifications 100-240V~,50/60Hz,0.6A
    General
    Working Temperature -20℃~+60℃
    Storage Humidity 0%RH~80%RH
    Working Humidity 0%RH~80%RH
    Storage Temperature -40℃~+80℃
    Packaging Size (W × H × D) 385.0mm×280.0mm×75.0mm
    Net Weight 1228.9g
    Gross Weight 1648.5g
    Dimensions (W × H × D) 274.3mm×139.0mm×40.0mm
    Packing List
