| Cabinet |
| Pixel Configuration |
Flip-chip COB |
| Pixel Pitch Category |
P1.2 |
| Pixel Pitch |
1.25mm |
| Modules Component |
8 Panel |
| Dimensions (W × H × D) |
600 mm × 337.5 mm ×35 mm |
| Resolution |
480 × 270 |
| Area |
0.2025 m² |
| Weight |
4.5 Kg |
| Pixel Density |
1638400 dots/m² |
| Lamp Board Housing |
No housing |
| Cabinet Material |
Die-casting Aluminum |
| Maintenance Method |
Front |
| Cabinet Flatness |
0.1 mm |
| Protection Level |
Front protection level IP65 |
| Display |
| White Balance Brightness |
1000 cd/m² |
| Color Temperature |
3000 K to 10000 K adjustable |
| Viewing Angle |
Horizontal 150°, vertical 150° |
| Contrast Ratio |
18000 ：1 |
| Color Uniformity |
≤ ± 0.003Cx，Cy |
| Brightness Uniformity |
≥ 97％ |
| Dynamic Contrast Ratio |
1000000:1 |
| Processing Performance |
| Driving Method |
Constant current driving |
| Frame Frequency |
60 Hz |
| Refresh Rate |
Up to 3840 Hz |
| Grey Level |
Up to 13 bits |
| Display Color |
281 trillion |
| Power |
| Power Supply |
AC100～240V(50-60Hz) |
| Max. Consumption |
≤ 470 W/m² |
| Average Consumption |
< 157 W/m² |
| Working Environment |
| Working Temperature |
-10 ℃ to 40 ℃ (14 ℉ to 104 ℉) |
| Working Humidity |
10%~80%RH |
| Storage Humidity |
10%~80%RH |
| Storage Temperature |
-40 °C to 60 °C (-40 °F to 140 °F) |
| General |
| Gross Weight |
16.47 Kg |
| Package Dimension (W × H × D) |
712 mm × 362 mm ×448 mm (1 Package 4)( 28.03” x 14.25” x 17.64”) |
| Lifespan |
Lamp 100,000 hours |
